TOOLS TO DRESS AND TRUE GRINDING WHEELS
- PCD HYBRID
- Dressers with the superior form holding characteristics of PCD
but at a substantially lower cost
- CONTROLLED DISPERSION
- Dressers designed to provide the performance characteristics of dressers made by the reverse plated method, but is a sintered product
- HAND SET
- Diamonds are placed one at a time in a pre-determined pattern into the mold
- RAMDOM SET
- Diamonds are sprinkled in groups into the mold and “randomly”moved around to obtain spacing
- IMPREGNATED
- Diamonds are mixed with the matrix powder and inserted into the mold to the desired thickness, providing several layers of diamonds
- PLATED
- Electro-plating is used to apply diamonds directly on a straight or contour steel blank reverse electroplated type, which is made by internally plating a preformed mold similar to a conventional mold like that used in the Hand Set or Random Set types
-
- DIAMOND DRESSING BLOCKS
- Used when the rotary dressing system can not be adapted or the cost of the rotary system cannot be justified
|
